Name: Cambium Networks cnWave V3000 Client Node 60 GHz - 40.5 dBi antenne
Brand: Cambium Networks
SKU: C600500D002A-singlepack
Price: 102.75 EUR
Availability: InStock

Cambium Networks cnWave V3000 Client Node 60 GHz - 40.5 dBi antenne

60 GHz cnWave V3000 High-Gain Client Node

Cambium Networks' 60 GHz cnWave solution provides easy, fast and cost-effective wireless gigabit connectivity for edge access and/or high-capacity backhaul for edge access solutions at a significantly lower TCO than fiber infrastructure.

Service providers and enterprises now have access to gigabit for business and residential connectivity, backhaul for Wi-Fi access or LTE/5G small cell. Certified for Facebook Terragraph, cnWave solutions are highly efficient at handling high-density deployments in cities and suburban areas.

V3000 is featured with 40.5 dBi high-gain antenna with beamforming. The Client Node (CN) can be used as either a client in PMP configurations or an end-point in PTP configurations.

Supports 57 to 66 GHz
Up to 3.6 Gbps (1.8 Gbps DL and 1.8 Gbps UL). Channel bonding typically doubles capacity
Easy installation with autobeamforming
Low latency < 1 ms
802.11ay technology with Terragraph certification

PLEASE NOTE:
Power Supply Unit must be ordered separately.

Spectrum, Interface & Networking

Frequency Range	57 to 66 GHz in a single SKU 200
Channel Width	2.16 GHz, 4.32 GHz*
Carrier Bonding*	Up to 2 adjacent channels
Mode of Operation	PMP Client or PTP
Channel Access	TDMA/TDD
Ethernet Interface	1 x 100/1000/10G BaseT with PoE In, 1 x 100/1000 BaseT with 802.3at PoE Out, 1 x SFP+ 1G and 10G
Protocols Supported	IPv4, IPv6, Layer2 Bridge, Layer3 IPv6 Routing, Open/R mesh
Network Management	cnMaestro, HTTP, HTTPS, SNMP v2c & v3
MTU	4,000 bytes
VLAN	802.1ad (QinQ), 802.1Q with 802.1p priority
QoS	4 Level QoS, DSCP and VLAN Tag

Security, Performance & Antenna

Encryption	128-bit AES
Firmware Security	Signed Firmware Images
Modulation & Coding Schemes	MCS-0 (BPSK) to MCS-12 (16-QAM)
Latency	< 1 ms
Maximum EIRP	54.5 dBm (with 40.5 dBi Antenna)
Gain	40.5 dBi
Type	Integrated
Beamforming Scan Range	+/- 2 degrees azimuth, +/- 1 degrees elevation
Beam Width	0.8 degrees

Powering & Physical

Type	Passive PoE (42-57V) without AUX PoE Out in use
Power Consumption	60 W with AUX PoE Out in use, 30 W without AUX PoE Out in use
Environmental	IP66/67
Temperature	-40 C to 60 C
Mean Time Between Failure	> 40 years
Weight	3.9kg without clamp
Dimensions	343 x 198 x 251 mm
Wind Survival	200 km/h
