MikroTik hEX PoE RB960PGS

hEX PoE is a five port gigabit ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit.

It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded.

Specifications RB960PGS

Architecture: MIPSBE
CPU: QCA9557
CPU core count: 1
CPU nominal frequency: 800 MHz
License level: 4
Operating System: RouterOS
Size of RAM: 128 MB
Storage size: 16 MB
Storage type: FLASH
Tested ambient temperature: -40 C to 60 C

PoE in: Passive PoE
PoE in input Voltage: 12-57 V
PoE out: 802.3af/at
PoE-out ports: Ether2-Ether5
Number of DC inputs: 2 (DC jack, PoE-IN)
DC jack input Voltage: 12-57 V
Max out per port output (input > 30 V): 450 mA
Max out per port output (input < 30 V): 1 A
Max total out (A): 2 A
Max power consumption: 54 W
Max power consumption without attachments: 6 W
10/100/1000 Ethernet ports: 5
SFP ports: 1
