Konftel CC200 Video System




717,50 592,98 excl. BTW
- Op een werkdag voor 16:30 besteld, morgen in huis!
- Gratis verzending binnen de Benelux
- Installatieservice kant-en-klaar of op locatie
- Kopen op rekening voor de zakelijke markt
- Professioneel advies
PRODUCT INFORMATIE.
-
Product name: Konftel CC200
Item no.: 931501001
Contents: Konftel CC200, Lens cap, Remote control with qwerty keyboard and two AAA batteries, Wall mount with screws, Power adapter 220V (EU, US, AU, UK), HDMI Cable 1.5 m, 90° HDMI adapter, Quick Guide and Safety instructions.
Size: 28.0 (11.0”) x 5.5 (2.2”) x 6.5 cm (2.6”) (LxWxH)
Weight: 0.68 kg
- COMMUNICATIONS
-
IP: H.323, SIP (RFC 3261).
Bit rate: H.323/SIP up to 4Mbps
MCU compatibility: H.243, H.231 XMPP Presence support.
- CAMERA
-
Sensor: 4Kp30
Video resolution: 1080p30
Horizontal Field of View: 102°
Vertical Field of View: 68°
Digital zoom: 5x
Preset: up to 122 presets (web managed), up to 10 presets
(GUI managed).
- VIDEO
-
Video features: Two simultaneous channels: camera + content.
Video protocols:
H.264, H.264 High Profile.
Dual: H.239 (H.323) and BFCP (SIP)
SVC (Scalable Video Coding) H.263+ is supported with resolutions up to [email protected] Only RFC2429 is supported. Custom formats and annexes are not supported.
Video input:
Live video from built in camera up to 1920 x 1080p30fps.
Wireless presentation up to 1920 x 1080p15fps.
Video output:
1x HDMI, 3840 x [email protected], 30fps; 1920 x [email protected],
30fps; 1280 x [email protected], 30fps
Live video encoding format:
1920 x [email protected], 30fps
1280 x [email protected], 30fps
1024 x [email protected], 30fps: w576p
848 x [email protected], 30fps: w480p
768 x [email protected], 30fps: w448p
704 x [email protected], 30fps: 4CIF
704 x [email protected], 30fps: 4SIF
624 x [email protected], 30fps: w352p
576 x [email protected], 30fps
512 x [email protected], 30fps: wCIF
416 x [email protected], 30fps: w240p
400 x [email protected], 30fps
352 x [email protected], 30fps: CIF
352 x [email protected], 30fps: SIF-
Audio features:
Acoustic echo cancellation
Audio error concealment
Automatic Gain Control (AGC)
Automatic noise suppression
Audio protocols:
G.711, G.719, G.728 and G.729 A/B, G.722, G.722.1, G.722.1
Opus Annex C
Microphone: Microphone array
- CONNECTIVITY
-
USB ports: 1 x USB-C, 1 x USB 3
Audio inputs: Bluetooth, USB
Audio outputs: 1 x HDMI, Bluetooth, USB
- CONTENT SHARING
-
Content sharing / Web collaboration features:
Wireless presentation (Wi-Fi Display – Miracast) up to 1080p15fps.
Present content using Android Apps and USB memory stick.
Share content through HDMI using the optional Konftel AV grabber connected to the USB port (optional accessory). Supported laptop resolutions are as follows:
1920x1080p30, 50, 60
1680x1050p60
1280x1024p60
1280x720p50, 60
1024x768p60
800x600p60
Content sharing / Split & share / Web collaboration protocols:
Dual video: H.239 (H.323), BFCP (SIP).
Wireless screen sharing (Wi-Fi Display – Miracast).
- NETWORK AND COMMUNICATION
-
Network features:
IPv4 and IPv6 simultaneous support.
Auto Gatekeeper discovery.
QoS support: IP Precedence, IP Type of Service (ToS),
Differentiated Services (diffserv).
IP adaptive packet management:
Flow control.
Packet Loss based down-speeding.
Packet Loss recovery policies.
Security features:
Embedded encryption.
H.323 security per H.235v3 / Annex D. SIP security per SRTP and TLS 1.2, enciphering up to AES-256.
SIP “Digest” authentication (MD5) RTP media enciphering with AES-256.
Public-Key including Diffie-Hellman (2048 bits), RSA (up to 4096 bits).
Cryptographic hash (up to SHA-512).
Web access via HTTPS.
Selective enable / disable of IP features.
White list support.
Firewall traversal:
Auto NAT discovery HTTP and STUN H.460.18, H.460.19 “Keep Alive” packet time configurable.
Network protocols:
DHCP, DNS, HTTP, HTTPS, RTP/RTCP, SNTP, STUN, TCP/IP, TELNET, TFTP , 802.1q and 802.1p.
Network interfaces:
10/100/1000 Base-T full-duplex (RJ-45).
Wi-Fi (802.11a/b/g/n, 802.11ac, Hotspot).
- POWER SUPPLY
- 100-240VAC, 50-60Hz, 2.5A max.
-
Audio features:
- USER INTERFACE
-
User interface:
25 language on-screen user interface.
Infrared remote control.
API for endpoint control.
Microsoft Exchange calendar integration.
Android™ apps can be downloaded on the device and used alongside the Konftel CC200 video-communication application (Android is a trademark of Google LLC).
Google Services Framework support by means of OpenGapps.
Touch Screen Monitor control supported.
Group Framing support for huddle rooms.
External Keyboard/Mouse supported through USB interface or Bluetooth.
Directory service & address book:
LDAP Client (H.350).
Receive global address book from enterprise LDAP Server.
Web management:
Configuration, call, diagnostics and management functions are accessible with Internet Explorer 8.0+, Firefox 3.6+, Safari 5.0+, Chrome 11.0+ and Opera 11+.
Automatic Firmware Upgrade through Cloud.
Meeting recording:
Recording on USB memory stick.
Feature supported in call and outside of a call.
Supported disks with file system FAT32, EXT2, EXT3 and EXT4.
Recorded file resolution 720p25 (rescaled to 720p when exceeding such resolution).
Control API commands available to transfer the recorded file to a remote FTP server.
Digital signature for recorded files.
Merk | Konftel |
Artikelnummer | 931501001 |
EAN | 07394001011305 |
