Name: Ubiquiti UniFi Switch 24 Gen2 (non-poe)
Brand: Ubiquiti
SKU: USW-24
Price: 231.25 EUR
Availability: InStock

Ubiquiti UniFi Switch 24 Gen2 (non-poe)

The USW-24 is a configurable Layer 2 switch with 24 Gigabit Ethernet ports and 2 SFP ports. The SFP ports provide 1 Gbps fiber uplink options to your enterprise network. The USW-24 features a 1.3" touchscreen, compact size, and fanless design. The touchscreen displays the current switch state and information for quick diagnosis. Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24 switch offers an extensive suite of advanced Layer 2 switching protocols and features, including operating mode (switching, mirroring, or aggregate) per port.

Mechanical:

Dimensions	442 x 200 x 44 mm (17.4 x 7.9 x 1.7")
Weight	Without mounting brackets: 2.7 kg (6 lb) With mounting brackets: 2.8 kg (6.2 lb)
Enclosure material	SGCC steel

Hardware:

Management interface	Ethernet In-Band
Networking interface	(24) GbE RJ45 ports (2) 1G SFP ports
Total non-blocking throughput	26 Gbps
Switching capacity	52 Gbps
Forwarding rate	38.69 Mpps
Power method	Universal input, 100—240V AC, 50/60 Hz
Power supply	AC/DC, internal, 36W
Supported voltage range	100—240V AC
Max. power consumption	25W
ESD/EMP protection	Air: ± 16kV, contact: ± 12kV
LCM display	(1) 1.3" touchscreen
Button	Factory reset
Ambient operating temperature	-5 to 45° C (23 to 113° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC

Switching features:

Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	–
