General

SFP Transceiver Type: Phase optics

Maximum Data Rate: 10,000 Mbit/s
Interface: SFP+

Compatible Products: HP BladeSystem c-Class

Certification: MSA

Power Consumption (Standard Business): 0.8 W
Width: 13.4 mm
Depth: 56.5 mm
Height: 8.5 mm
Number of Products Included: 1 piece

Performances

SFP Transceiver Type: Phase optics
Maximum Data Rate: 10,000 Mbit/s
Interface: SFP+
Multi-Mode Phaser (MMF) Supported: Yes
Optical Cable Connector: LC
Supported Fiber Cable Diameters (Core/Sheath): 50/125, 62.5/125 µm
SFP Transceiver Standard: SR
Maximum Possible Transmission Distance: 400 m
Wavelength: 850 nm
Network Standard: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u
Cabling technology: 10GBASE-SR
Duplex System: Full
Auto MDI/MDI-XYes
Goods tariff number (HS): 85369010
Features:
Hot-plug support: Yes
Hot-swap: Yes
Compatible Products: HP BladeSystem c-Class
Certification: MSA
Packaging data:
Number of products included: 1 piece
Operating conditions:
Operating temperature: 0 - 70 °C
Temperature range at storage: -40 - 85 °C
Relative air quality at operation: 10 - 80 %
Relative air quality at storage: 10 - 85 %
Weight and measurements:
Width: 13.4 mm
Depth: 56.5 mm
Height: 8.5 mm
Performance:
Power consumption (standard business): 0.8 W
